VMP Multi-Just™ Flat Panel Flush Mount with Tilt

A Highly Adjustable, Sturdy, and Affordable Wall Mount for Your Flat Screen TV

Qty:

What's special about this television mount?

  • Ideal for securely mounting flat panel televisions ranging between 27" and 42" in your home theater, office, or hospitality application.
  • Tilt adjustment from -5° to 15° delivers a wide range of correction for achieving the perfect picture from any distance or angle.
  • Integrated “kickstand” temporarily spaces television from the wall once installed, allowing easy access to cabling for installation and replacement.
  • Formed, arc-welded steel frame provides durability that can be trusted to protect your investment.
  • Click for More Features

Any old flat panel mount will "do the trick", but achieving a streamlined, dynamic theater display sometimes requires learning a few new tricks.  The Multi-Just™ flat screen mount from Video Mount Products provides many angles of adjustment, eliminating some of the most common viewing problems with flat displays. This solid mount makes a great solution for home theater, hospitality and entertainment applications.

Note: VMP Products cannot be returned if removed from Original Package unless Defective.
Please be sure to review your packaged item before opening to make sure you received the correct product

Part # IMG Description Television Size Range Weight Capacity Dimensions Color Weight Price
VMP-FP-MFTB flat panel flush mount drawing VMP Multi-Just™ Flat Panel TV Wall Mount 27" to 42" 100 lbs (45.35 kg) 19" x 15.75" x 2.3"
(48.26 x 40.00 x 5.84)		 Black 5.55 lbs (2.51 kg)
Qty:
Manufacturer Direct
  • List adjustment of ±3° allows you to slightly adjust either side of the frame vertically, so you do not have to re-install if there is a slight mistake in the initial installation.
  • 100 lb (45.35 kg) weight capacity is sure to accommodates almost any modern flat panel television.
  • Optional Component Shelf provides a low profile way to mount DVD/Blu-ray players, DVRs, gaming systems and other components.
  • All necessary mounting hardware is included for a secure, professional installation to 2 wall studs.
  • Black powder coat finish resists corrosion

    •

    DRAWINGS & SPECS -

  • Technical Drawing (PDF) PDF
  • Specifications Sheet (PDF) PDF

    •

    PROPERTY VALUE
    TV Size Range 27" to 45"
    Tilt Range -5° to 15°
    Vertical Height adjustment 1" (2.54 cm)
    List adjustment ±3°
    Wall Gap 2.3" (5.84 cm)
    Load Capacity 100 lbs (45.35 kg)
    Maximum Flat Panel Hole Pattern 415mm x 345mm
    Stud Distance Up to 16" (40.64 cm) apart
    Dimensions 19" x 15.75" x 2.3"
    (48.26 x 40.00 x 5.84)
    Weight 5.55 lbs (2.51 kg)
    Shipping Dimensions 19.75" x 7" x 3.25"
    (48.26 x 17.78 x 5.84)
    Shipping Weight 8 lbs (3.62 kg)
    Material Formed, Arc Welded Steel
    Finish Black Powder Coat
