Great Lakes Wall Mount Enclosures - WS Series

Name: Great Lakes Wall Mount Enclosures - WS Series
SKU: QGL-GL24WS-SS

Center Swing-Out Gives Unbeatable Access to Network Equipment and Cables

Enclosure

QGL-GL24WS-SS

Accessories

QGL-7217WS

What's special about these wall mount enclosures?

Made of 14 Gauge cold rolled steel fully welded; front door is made from 12 Gauge.
UL listed per STD 508, Type 1
UL 2416
Click for More Features

The Wall Mount/Swing Out WS Series Enclosures provide 19" 310-E compliant mounting in a heavy duty distribution unit. This durable enclosure features a center swing out section for outstanding front and rear access to cables and equipment. A simple finger pull-latch mechanism located inside the enclosure swings the 18.375" deep center swing section open from the rear.

All accessories installed into enclosures before shipping at no additional cost upon request

Part #	U/ Rms	Door &Amp; Sides	Dimensions	Load Capacity	Color	Price
QGL-GL24WS-SS	11 U	Solid Front Door & Solid Sides	24" H x 24" W x 24" D	250 lbs	Black	Qty: Manufacturer Direct
QGL-GL24WS-SV	11 U	Solid Front Door & Vented Sides	24" H x 24" W x 24" D	250 lbs	Black	Qty: Manufacturer Direct
QGL-GL24WS-PS	11 U	Plexi Front Door & Solid Sides	24" H x 24" W x 24" D	250 lbs	Black	Qty: Manufacturer Direct
QGL-GL24WS-PV	11 U	Plexi Front Door & Vented Sides	24" H x 24" W x 24" D	250 lbs	Black	Qty: Manufacturer Direct
QGL-GL24WS-MS	11 U	Mesh Front Door & Solid Sides	24" H x 24" W x 24" D	250 lbs	Black	Qty: Manufacturer Direct
QGL-GL24WS-MV	11 U	Mesh Front Door & Vented Sides	24" H x 24" W x 24" D	250 lbs	Black	Qty: Manufacturer Direct
QGL-GL36WS-SS	18 U	Solid Front Door & Solid Sides	36" H x 24" W x 24" D	300 lbs	Black	Qty: Manufacturer Direct
QGL-GL36WS-SV	18 U	Solid Front Door & Vented Sides	36" H x 24" W x 24" D	300 lbs	Black	Qty: Manufacturer Direct
QGL-GL36WS-PS	18 U	Plexi Front Door & Solid Sides	36" H x 24" W x 24" D	300 lbs	Black	Qty: Manufacturer Direct
QGL-GL36WS-PV	18 U	Plexi Front Door & Vented Sides	36" H x 24" W x 24" D	300 lbs	Black	Qty: Manufacturer Direct
QGL-GL36WS-MS	18 U	Mesh Front Door & Solid Sides	36" H x 24" W x 24" D	300 lbs	Black	Qty: Manufacturer Direct
QGL-GL36WS-MV	18 U	Mesh Front Door & Vented Sides	36" H x 24" W x 24" D	300 lbs	Black	Qty: Manufacturer Direct
QGL-GL48WS-SS	25 U	Solid Front Door & Solid Sides	48" H x 24" W x 24" D	350 lbs	Black	Qty: Manufacturer Direct
QGL-GL48WS-SV	25 U	Solid Front Door & Vented Sides	48" H x 24" W x 24" D	350 lbs	Black	Qty: Manufacturer Direct
QGL-GL48WS-PS	25 U	Plexi Front Door & Solid Sides	48" H x 24" W x 24" D	350 lbs	Black	Qty: Manufacturer Direct
QGL-GL48WS-PV	25 U	Plexi Front Door & Vented Sides	48" H x 24" W x 24" D	350 lbs	Black	Qty: Manufacturer Direct
QGL-GL48WS-MS	25 U	Mesh Front Door & Solid Sides	48" H x 24" W x 24" D	350 lbs	Black	Qty: Manufacturer Direct
QGL-GL48SW-MV	25 U	Mesh Front Door & Vented Sides	48" H x 24" W x 24" D	350 lbs	Black	Qty: Manufacturer Direct

Accessories
Part #	Description	Color	Price
QGL-7217WS	Fan Assembly w/ fan guards & (2) 75 CFM Fans *	Black	Qty: Manufacturer Direct

Shelves
Part #	Description	Color	Price
QGL-7206-FM	Stationary Front Mount Shelf - 17.25" W x 18" D for 19" Mounting - 60 lbs weight capacity	Black	Qty: Manufacturer Direct
QGL-7206-EIA	Stationary Shelf - 17.468" W x 18" D for 19" Mounting - 80 lbs weight capacity	Black	Qty: Manufacturer Direct
QGL-7206-SL	Sliding Shelf - 16.343" W x 17.5" D for 19" Mounting - 40 lbs weight capacity **	Black	Qty: Manufacturer Direct

Power Strips, Cooling Equipment, Hardware
Part #	Description	Color	Price
QGL-7219	6 Position Power Strip w/ Circuit Breaker, 5-15P plug for 19" Mounting ***	Black	Qty: Manufacturer Direct
QGL-7219-20AR	6 Front Outlets, Circuit Breaker, 5-20P Plug, 19" long	Black	Qty: Manufacturer Direct
QGL-7208WS	Casters - (2) Locking & (3) Non-Locking	Black	Qty: Manufacturer Direct
QGL-7208WS-ALL	Casters - (5) Locking	Black	Qty: Manufacturer Direct
QGL-CBB-19	19" Rack Mounted Copper Bus Bar (Isolated)	n/a	Qty: Manufacturer Direct

* 7217WS fan assemblies are UL approved if installed by GLCC during initial shipment
** 7206-SL sliding shelf uses 14" slides rated at 60 lbs
*** All power outlet strips supplied with circuit breakers and 15' cord. All components UL approved

ISO 9001:2000 registered

Choose your front door style (solid or plexiglas)

Front door locks

Interchangeable side panels

Two pairs of 12-24 tapped 19" EIA rails (12 Gauge), adjustable front to rear are provided with each enclosure.

Swing out center section

Front and rear cable access

Provisions for 2 low profile 75 cfm fans at top or bottom (does NOT include fans).

Knockouts designed for 1", 2", and 3" conduit at top, bottom and rear sections.

Reversible mounting to conserve space

Easy wiring, installation and maintenance

Great Lakes Features:

8 week shipping time on custom changes

Custom colors available upon request (Additional charge may apply. Please allow up to an additional 4 week ship time)

Custom configurations assembles in 24-48 hours

Accessories installed where you specify

No additional freight charges for installed options

Shelves placed where you specify
Mounting rails located where you specify
Cable Management installed where you specify
Power outlet strips installed where you specify

No additional cost for drop ship

All enclosures have a Serial Number

Remote installation of equipment before wiring is possible with a set of optional casters. They increase the weight capacity and stability of the enclosure and also make the enclosure ready for disaster preparedness.

The Wall mount enclosure must be UL listed per STD 508, Type 1 and 24, 36, 48, 72 "H x 24 "W x 24."D

Unit must be 3 "piece" sectional design using HD bolt on steel hinged between wall section and middle section. Lockable front solid or plexi door. Pull latch system to open secured middle section. Wall mount to be reversible allowing for right or left hand swing. Top and bottom set up to accept fan assembly and set of 6 casters. Black powder coat finish on 14-gauge steel.

Manufacturer must be ISO 9001:2000 registered

Mounting - The base unit must have 2 pair of 19" rack mount rails that are tapped 12-24. Adjustable front to rear.

Cable Access -Rear section to have 3 knockouts in center back and top/bottom for conduit sizes 1, 2 & 3".

Doors -Doors to be plexi-glass or solid. Base unit must have gasketing for the doors.

Sides - Sides of center section to have option for solid or vented sides

Cable Management- all 19" rack mounted cable management to be installed, preferably on the rear rails.

Power Strips - all 19" rack mounted power strips to be installed on the rear rails.

Fans- 2 low profile 75cfm fans

Finish (Paint) : Black, White and Nitro Blue available in an electrostatic powder coat finish (3 coats)

View colors (Custom designed and colored upon request. Please contact us for more information)

PART #	OVERALL DIMENSIONS	RACK SPACE	WEIGHT CAPACITY	SHIPPING WEIGHT	SHIPPING DIMENSIONS (HxWxD)
QGL-WM-24WS	24"H x 24"W x 24"D	11 U	250 lbs *	125 lbs	27" x 24" x 20.5" **
QGL-WM-36WS	36"H x 24"W x 24"D	18 U	300 lbs *	150 lbs	27" x 24" x 26" **
QGL-WM-48WM	48"H x 24"W x 24"D	25 U	350 lbs *	200 lbs	39" x 24" x 26" **

* Maximum weight capacities at minimal deflection. Weight capacities are listed for wall mounting only. Up to 850 lbs. weight capacity is possible using a combination of wall mounting and casters.
** Multiple units to same location will get skidded
