What's special about these mounts?
- Easy to install, remove and reposition with just a quarter-turn – no tools necessary.
- Multi-directional cable tie slot allows for routing a bundle parallel to or perpendicular to the frame.
- Low profile is ideal for cramped spaces.
- Designed to fit an 80/20 profile with a T-slot of 8 mm (0.32") and external dimensions of 40 mm (1.5").
-
Aluminum frame mounts can be used with 20, 30 or 40 mm square frames from the major aluminum frame manufacturers. As there is no need to screw them in place, these mounts offer maximum ease of use and fast installation. The mounts contain metal particles for detection in processing plants where the potential for contamination is undesirable.
| Aluminum Frame Mounts | |||||||
|---|---|---|---|---|---|---|---|
| Part # | Description | Panel Thickness | Material, Color, Qty. | Price | |||
| HT-151-01611 | Aluminum Frame Mount for 40mm Frame | 2.5 - 3.0mm Panel Thickness | PA66, White, 100/bag | Quick Ship
| |||
| HT-151-02567 | Aluminum Frame Mount for 1.5" Frame | 2.5 - 3.0mm Panel Thickness | PA66MP+, Blue, 100/bag | Quick Ship
| |||
| HT-151-02949 | Aluminum Frame Mount for 40mm or 1.5" Frame | 4.0 - 4.8mm Panel Thickness | PA66MP+, Blue, 100/bag | Quick Ship
| |||
| HT-151-01612 | Aluminum Frame Mount for 40mm or 1.5" Frame | 4.0 - 4.8mm Panel Thickness | PA66, White, 100/bag | Quick Ship
| |||
| Part # | Description | Panel Thickness | Material, Color, Qty. | Cable Ties | L X W X H (Imperial) | Flammability | Operating Temp. | UV resistnat | Reach Compliant (Article 33) |
|---|---|---|---|---|---|---|---|---|---|
| HT-151-01611 | Aluminum Frame Mount for 40mm Frame | 2.5 - 3.0mm Panel Thickness | PA66, White, 100/bag | T18 - T50 | 1.02 x 0.71 x 0.68 | UL 94 HB | -40°F to +185°F (-40°C to +85°C) | No | No |
| HT-151-02567 | Aluminum Frame Mount for 1.5" Frame | 2.5 - 3.0mm Panel Thickness | PA66MP+, Blue, 100/bag | T18 - T50 | 1.02 x 0.71 x 0.68 | UL 94 V-2 | -40°F to +185°F (-40°C to +85°C) | No | No |
| HT-151-02949 | Aluminum Frame Mount for 40mm or 1.5" Frame | 4.0 - 4.8mm Panel Thickness | PA66MP+, Blue, 100/bag | T18 - T50 | 1.10 x 0.83 x 0.80 | UL 94 HB | -40°F to +185°F (-40°C to +85°C) | No | No |
| HT-151-01612 | Aluminum Frame Mount for 40mm or 1.5" Frame | 4.0 - 4.8mm Panel Thickness | PA66, White, 100/bag | T18 - T50 | 1.10 x 0.83 x 0.80 | UL 94 V-2 | -40°F to +185°F (-40°C to +85°C) | No | No |
