What's special about this monitor?
- Suitable for All Video Surveillance and Security applications
- Full High Definition Quality: 1920 x1080
- Bright LED Illuminated Panel with 178° Viewing Angle
- Inputs: HDMI, VGA, BNC
- Outputs: BNC
- 16.7 Million Color Capacity
- VESA Mount Compatible
Item | Part # | Description | Price |
---|---|---|---|
|
IMHD-22HVB | 21.5" Full HD LED Monitor, 1920 x 1080 Resolution, HDMI, VGA & Looping BNC Inputs, BNC Ouput, Includes Low Voltage Brick | |
Mode Name |
IMHD-22HVB |
Screen Size |
22'’ |
Active Display Area (mm) |
476.64mm(W)×268.11mm(H) |
Display Mode |
16:9 |
LED Type |
TFT-LED |
Resolution |
1920 × 1080 |
Display Color |
16.7M |
Pixel Pitch (mm) |
0.248(H)×0.248(V) |
Brightness (nits) |
300cd/m2 |
Contrast Ratio |
10000:1 |
Viewing Angle |
178(H) /178(V) |
Response Time |
5ms |
Backlight |
LED |
Input & Output |
|
HDMI 2.0 |
1 |
VGA |
1 |
BNC input |
2 |
BNC output |
1 |
Speaker |
2x3W (Stereo) |
Video |
|
Color System |
PAL/NTSC/SECAM |
OSD Control |
Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language.. |
3D comb filter |
Yes |
Video Noise Reduction |
Yes |
Power & Mount Way |
|
Power |
DC12V ,50/60Hz |
Working Temperature |
-22°F to 185°F (-30 to +85 ℃) |
Power Consumption |
≤25W |
Menu |
Chinese/English(other languages supported) |
Mounting/Weight |
Stand mount, VESA mount/3.5kg |
MTBF |
50000Hours |
Accessories |
|
Included Accessories |
Industrial PSU, Screw, Cable holder, Quick start guide |
