CHIEF® iC® Tilting Monitor Mounts
Tilt Your Screens To the Perfect Position
|
What's special about these tilting screen mounts?
The ability to mount a monitor or television on the wall allows you to save space and adding to this commodity is the tilting ability of the iC® Tilting Mounts by CHIEF®. A secure wall mounted monitor can be tilted into a desired position to facilitate the viewing experience. This item comes in many different sizes and weight capacities to fit just about any size screen.   |
- Elegant design matches modern look
- Heavy duty construction for durability
- Broad range of motion for your desired position
- Wall or cabinet mounting increase possibilities for placement
- All hardware is included for a fast set up
Monitor Mount Dimensions
| PART # | DESCRIPTION | DIMENSIONS | WEIGHT | SCREEN SIZE | WEIGHT CAPACITY |
| CHI-ICSPTM1T02 | Small Screen Tilt Wall Mount | 5"H x 8.5"W x 2.37"D | 4 lbs | 10" - 32" | 45 lbs |
| CHI-ICSPTP2T02 | Tilt & Swivel Wall Mount | 6.5"H x 4.69"W x 3.34"D | 4 lbs | 10" - 26" | 40 lbs |
| CHI-ICSPUC1T02 | Swing Down Screen Mount | 1.73" - 11.03"H x 5.44"W x 6.59" - 9.41"D | 4 lbs | 10" - 17" | 15 lbs |
| CHI-ICMPTM1T02 | Medium Screen Tilt Wall Mount | 16.5"H x 21.3"W x 3.26"D | 13 lbs | 23" - 46" | 100 lbs |
| CHI-ICLPTM1T02 | Large Screen Tilt Wall Mount | 18"H x 29"W x 3.26"D | 16 lbs | 30" - 60" | 175 lbs |
Monitor Mount Drawings
) |
) |
| Dimensions for Small Tilting Monitor Mount | Dimensions for Medium Tilting Monitor Mount |
) |
|
| Dimensions for Swing Down Under Cabinet Monitor Mount | |
Component Dimensions
| PART # | OVERALL | WEIGHT CAPACITY | ||
| WIDTH | HEIGHT | DEPTH | ||
| CHI-ICFPAC2T02 | 3.25" [83mm] | 19.6" [498mm] | 1.25" [32mm] | n/a |
| CHI-ICFPAC3T02 | 11.99" [305mm] | 6.0" [152mm] | 15.87" [403mm] | up to 40 lbs [18.14kg] |
Component Drawings
) |
) |
| Dimensions for Cable Channel | Dimensions for Component Shelf |
| PART # | DESCRIPTION | FOR SCREEN SIZES | SHIPPING WEIGHT | PRICE Add Quantity at Checkout |
| CHI-ICSPTM1T02 | CHIEF® iC® Small Tilt Screen Wall Mount | 10" - 32" | 4 lbs | $49.99 |
| CHI-ICSPTP2T02 | CHIEF® iC® Small Tilt & Swivel Screen Wall Mount | 10" - 26" | 4 lbs | $69.99 |
| CHI-ICSPUC1T02 | CHIEF® iC® Swing Down Mount | 10" - 17" | 4 lbs | $99.99 |
| CHI-ICMPTM1T02 | CHIEF® iC® Medium Tilt Screen Wall Mount | 23" - 46" | 13 lbs | $119.99 |
| CHI-ICLPTM1T02 | CHIEF® iC® Large Tilt Screen Wall Mount | 30" - 60" | 16 lbs | $149.99 |
Accessories
| PART # | DESCRIPTION | WEIGHT | PRICE Add Quantity at Checkout |
| CHI-ICFPAC2T02 | CHIEF® iC® Component Shelf | 4 lbs | $29.99 |
| CHI-ICFPAC3T02 | CHIEF® iC® Cable Channel | 2 lbs | $19.99 |
) |
) |
| Tilting Wall Mount - Small | Box for Small Wall Mount |
) |
) |
| Tilting Wall Mount - Medium | Box for Medium Wall Mount |
) |
) |
| Tilting Wall Mount - Large | Box for Large Wall Mount |
) |
) |
| Tilt & Swivel Monitor Wall Mount | Box for Tilt & Swivel Wall Mount |
) |
) |
| Swing Down Under Cabinet Mount | Box for Swing Down Monitor Mount |
) |
) |
| Cable Channel | Box for Cable Channel |
) |
) |
| Component Shelf | Box for Component Shelf |
MANUALS -
- Small Tilting Wall Mount - Manual (PDF)
1.5MB - Medium Tilting Wall Mount - Manual (PDF)
12MB - Under Cabinet Swing Down - Manual (PDF)
2MB - Cable Channel Installation Manual (PDF)
- Component Shelf Installation Manual (PDF)
